RFI Legion 6-in-1 Screw Mount Antenna, 4x 5GNR, 2x WiFi, 4x SMA-Male, 2x SMA-Male RP

    RFI Legion 6-in-1 Screw Mount Antenna, 4x 5GNR, 2x WiFi, 4x SMA-Male, 2x SMA-Male RP

      Product form
      Brand:
      Item ID:
      168069220
      Export:
      Accepted
      Shipping:
      Please contact us for lead time
      Warranty:
      Standard Warranty
      Product Liability:
      Global Insurance Except USA & Canada
      Options/MPN:
      LEGION-C4-W2-2M-SMA

      Request for Quote (RFQ) Discount Offers Shipping Policy Returns Policy
      RFI LEGION 6-in-1 Screw Mount Antenna, 4x 5GNR, 2x WiFi, 4x SMA(M), 2x SMA(M) RP is an ideal solution for OEM manufactures, and emergency services.

      $350.50 incl. GST

      •  Please contact us for lead time.
      • Pay securely! All major cards accepted.

        shop pay

      Product Description

      The LEGION-C4-W2-2M-SMA 6-in-1 Combination antenna boasts 4x4 ultra-wideband cellular, and Multiband 2x2 MIMO Wi-Fi. The simple screw mount system makes mounting and installation simple and easy. This makes the Legion an ideal solution for OEM manufactures, and emergency services. The ultra wideband 4x4 MIMO cellular feeds cover 617-5925 MHz Sub 6GHz Bands allowing for the Legion MINI to be used with a wide variety of communication technologies. I0ncluding: 5GNR, 4G LTE, FirstNet, CBRS, LPWA, CAT-X, CAT-Mx, CAT-NBx, NB-IoT, 3G and 2G standards. The 2x2 MIMO Wi-Fi feed support 2.4/5.0/6.0 GHz allowing for Wi-Fi 6E and 7 support. With wideband cellular and Wi-Fi in a low profile compact radome the Legion is ideal for a variety of applications including:
      • Fixed wireless including Data Terminals, Base Stations and Routers
      • Utilities
      • IoT and M2M
      • Critical Communications and Public Safety (Law Enforcement & Fire Departments)


      Product Specifications

      Adapter included No
      MPN LEGION-C4-W2-2M-SMA
      Antenna application Terminal Antenna
      Antenna port connectors SMA (M), SMA (M) RP
      Antenna type Ground Independent
      Band 698-960 MHz / 1710-2170 MHz / 2500-2700
      Brands RFI
      Cable type D302
      Coverage type Omni-directional
      Frequency range mhz 1710 - 2170, 2300 - 2700, 698 - 960
      Height 2
      Ingress protection ip IP67, IP69
      Installation type Vehicle mounting
      Length 5
      Low pim No
      Max frequency mhz 7125
      Max gain dbd dbi 6.8
      Mimo support Yes
      Min frequency mhz 617
      Min gain dbd dbi 1.1
      Mount supported Screw mount
      Mount supported detailed Device mount
      No of antenna ports 6
      Nominal gain dbi 3.6dBi / 3.2 dBi / 1.9 dBi (peak)
      Packaging Clear Bag
      Power w 25.0, 25
      Radome diameter mm 50
      Technologies supported Wi-Fi, 5G
      Tuned bandwidth Full. No tuning required
      Vswr < 2.5:1
      Width 5
