RFI TLA2100 3G Transit Antenna, 824-2170 MHz, 5m, SMA-Male

    RFI TLA2100 3G Transit Antenna, 824-2170 MHz, 5m, SMA-Male

      Product form

      RFI 3G Transit Antenna (824-2170 MHz); 5m SMA(M) is an ideal antenna solution for 3G 850, GSM 900/1800 and 3G 2100 data applications

      Brand
      RFI
      Export
      Accepted
      Item ID
      168014342
      MPN
      TLA2100
      Shipping
      Not available to ship
      Standard Warranty Global Insurance Except USA & Canada

      Sold-out

      $212.83

      • Taxes included. Shipping rate calculated at checkout.
      • Purchase Order & instructions box available at Cart page

        • Pay securely! All major cards accepted.

          shop pay

        Product Description

        RFI 3G Transit Antenna (824-2170 MHz); 5m SMA(M)

        • Designed to offer true multi band performance, the TLA2100 is ready for use with the latest NEXT G modems
        • With a high impact resistant vacuum formed ABS radome and neoprene mounting gasket, the TLA2100 can be used for indoor or outdoor applications
        • Applications include public vending machines, ATM kiosks and industrial automotive use
        • Designed for use on conductive or nonconductive surfaces
        • TLA3100 model incorporates integrated GPS antenna

        Product Specifications

        Brand RFI
        Length (cm) 13.5
        Width (cm) 13.5
        Height (cm) 6.1
        Antenna Application Vehicle Antenna
        Antenna Features Multi Band Capable, Omnidirectional
        Antenna Port Connectors SMA (M)
        Antenna Type Low Profile Transit
        Band 824-960MHz / 1710-2170MHz
        Cable And Connector 5m of 9006 cable terminated with an SMA Male
        Cable Length (m) 5.0
        Cable Type 9006
        Coverage Type Omni-directional
        Frequency [MHz] 824-960|1710-2170
        Frequency Band Multi-Band 700-2700 MHz
        Installation Type Vehicle mounting
        Low PIM No
        Max Frequency (MHz) 2170
        Max Gain (dBd/dBi) 2.0
        MIMO Support No
        Min Frequency (MHz) 824
        Min Gain (dBd/dBi) 2.0
        No. of Antenna Ports 1
        Nominal Gain [dBi] 2
        Power [W] 10.0, 10
        Radome Diameter Mm 135
        Technologies Supported 3G
        Tuned Bandwidth Full. No tuning required
        VSWR <2.5:1
