RFI SP6938-2320-4.3 Directional Coupler, 3 Port, 20 dB, 694-3800 MHz, 200W, 4.3-10-Female
RFI SP6938-2320-4.3 Directional Coupler, 3 Port, 20 dB, 694-3800 MHz, 200W, 4.3-10-Female
RFI Directional Coupler 3 Port 20 dB 694-3800 MHz 200W; 4.3-10(F) are used in a variety of RF combining, sampling and power splitting applications.
- Brand
- RFI
- Export
- Acceptedwhat this means
- Item ID
- 168021574
- MPN
- SP6938-2320-4.3
- Shipping
- Ships out in 1-2 business days
Standard Warranty
Global Insurance Except USA & Canada
$180.46
- Taxes included. Shipping rate calculated at checkout.
- Purchase Order & instructions box available at Cart page
-
Pay securely! All major cards accepted.
Product Description
RFI Directional Coupler 3 Port 20 dB 694-3800 MHz 200W; 4.3-10(F)
RFI 3-Port Directional Couplers are used in a variety of RF combining, sampling RF for fibre fed systems and or distributing power throughout feeder cable networks. RFI provide a wide product range of coupling values in the most popular frequency bands which enables optimised and balanced system levels.Features:
- Broadband 694-3800 MHz covering multi-cellular bands
- Manufactured to a low PIM ? -160 dBc (3rd Order 2x43 dBm carriers) rating
- Primarily used for optimising feeder cable signal distribution.
- Suitable for use with simplex and duplex channels, analogue or digital communications.
- Suitable for use in multi-carrier environments
- Wide range of coupling values up to 30 dB
- Environmental IP 65 Rating.
