RFI SP6938-2308-4.3 Directional Coupler, 3 Port, 8 dB, 694-3800 MHz, 200W, 4.3-10-Female

RFI SP6938-2308-4.3 Directional Coupler, 3 Port, 8 dB, 694-3800 MHz, 200W, 4.3-10-Female

Available

Brand:
Item ID:
168021579
Export:
Accepted
Shipping:
Ships out in 1-2 business days
Warranty:
Standard Warranty
Product Liability:
Global Insurance Except USA & Canada
Options/MPN:
SP6938-2308-4.3
Send Request for Quote (RFQ) Discount Offers
RFI Directional Coupler 3 Port 8 dB 694-3800 MHz 200W; 4.3-10(F) are used in a variety of RF combining, sampling and power splitting applications.
Regular price $126.00
Regular price $0.00 Sale price $126.00
Sale Sold out
Taxes included Shipping calculated at checkout.
Quantity
View full details

Product Description

RFI Directional Coupler 3 Port 8 dB 694-3800 MHz 200W; 4.3-10(F)

RFI 3-Port Directional Couplers are used in a variety of RF combining, sampling RF for fibre fed systems and or distributing power throughout feeder cable networks. RFI provide a wide product range of coupling values in the most popular frequency bands which enables optimised and balanced system levels.

Features:

  • Broadband 694-3800 MHz covering multi-cellular bands
  • Manufactured to a low PIM ? -160 dBc (3rd Order 2x43 dBm carriers) rating
  • Primarily used for optimising feeder cable signal distribution.
  • Suitable for use with simplex and duplex channels, analogue or digital communications.
  • Suitable for use in multi-carrier environments
  • Wide range of coupling values up to 30 dB
  • Environmental IP 65 Rating.
Models available SP6938-23xx-4.3, where xx: | 05 | 06 | 07 | 08 | 10 | 13 | 15 | 20 | 30 |

Product Specifications

MPN SP6938-2308-4.3
Brands RFI
Component type Directional Coupler
Conn types all term ports 4.3-10 (F)
Connector 4.3-10 (F)
Coupled loss db 8
Finish Black - Painted
Frequency band Cellular
Height 8
Length 26
Pim 3rd 2 43 dbm dbc <160dBc
Width 15
