RFI TLA401-70 UHF Transit Antenna, 40mm, 450-470 MHz, 2 dBi, N-Female

    RFI TLA401-70 UHF Transit Antenna, 40mm, 450-470 MHz, 2 dBi, N-Female

      Product form
      Brand:
      RFI
      Item ID:
      168016148
      Export:
      Accepted
      Shipping:
      Ships out in 1-2 business days
      Warranty:
      Standard Warranty
      Product Liability:
      Global Insurance Except USA & Canada
      MPN/Options:
      TLA401-70
      Request for Quote (RFQ) Discount Offers Shipping Policy Returns Policy
      RFI TLA401-70 UHF Transit Antenna; 450-470 MHz; 40 mm Hole Spacing is a low profile transmission line antenna ideal for strict height requirements.

      Available

      $347.00

      • Taxes included. Shipping rate calculated at checkout.
      • Purchase Order & instructions box available at Cart page

        • Pay securely! All major cards accepted.

          shop pay

        Product Description

        The RFI TLA401-70 UHF Transit Antenna 450-470 MHz is a reliable and versatile antenna suitable for a wide range of applications. Its low profile and rugged construction make it an excellent choice for industrial, rail, and mining applications where durability and performance are essential. The RFI TLA401 is a low-profile transmission line antenna designed for applications with strict height requirements. Despite its compact size, measuring only 66mm tall, the TLA401 delivers performance equivalent to a traditional 3-wave whip antenna. This makes it an ideal choice for situations where height restrictions are a concern, such as industrial, rail, and mining applications.

        Features:

        • Low Profile: Only 66 mm tall, ideal for height-restricted applications.
        • Rugged Construction: Made from cast aluminum for durability in harsh environments.
        • Reliable Performance: Fully pattern tested in verified range conditions for consistent performance.
        • Corrosion Resistant: Designed to withstand exposure to moisture and environmental factors.
        • Fully Interchangeable: Hole spacing for mounting is 40mm, allowing for easy integration into existing setups.
        • Unity Gain: Provides unity gain over a ¼ wave for reliable signal transmission
        • Tuned Bandwidth: Supplied in 20 MHz bands with a VSWR of less than 1.5:1

        Documents:

        RFI TLA401 Series Antenna - Datasheet RFI TLA401 Series Antenna - Installation Guide

        Product Specifications

        MPN TLA401-70
        Antenna application Vehicle Antenna
        Antenna configuration SISO
        Antenna port connectors N (F)
        Antenna type Low Profile Transit
        Band 450 - 470MHz
        Brands RFI
        Coverage type Omni-directional
        Frequency band UHF 380-520 MHz
        Frequency mhz 380-520
        Height 6
        Installation type Vehicle mounting
        Length 25.5
        Low pim No
        Max frequency mhz 470
        Max gain dbd dbi 1
        Mimo support No
        Min frequency mhz 450
        Min gain dbd dbi 1
        Mount supported Screw mount
        Mount supported detailed Screw mount
        Mounting Screw and Gasket
        No of antenna ports 1
        Nominal gain dbi Unity
        Packaging Clear Bag
        Power w 100
        Technologies supported UHF
        Termination N connector, no cable supplied, order separately (UHF connector available subject to MOQ)
        Tuned bandwidth Supplied in 20 MHz bands @ <1.8:1 VSWR.
        Tuning Supplied pre-tuned
        Vswr Supplied in 20 MHz bands @ <1.5:1 VSWR.
        Whip material Rugged cast aluminium coated with baked enamel finish
        Width 6.65
