RFI HPA-4245-SMAF UHF Hand Portable Antenna, 420-450 MHz, 2 dBi, SMA-Female

    RFI HPA-4245-SMAF UHF Hand Portable Antenna, 420-450 MHz, 2 dBi, SMA-Female

      Product form

      RFI HPA-4245-SMAF UHF Antenna is ideal for workshop use, supplied factory tuned and offers superior performance in a variety of frequency bands.

      Brand
      RFI
      Export
      Accepted
      Item ID
      168015951
      MPN
      HPA-4245-SMAF
      Shipping
      Not available to ship
      Standard Warranty Global Insurance Except USA & Canada

      Sold-out

      $29.62

      • Taxes included. Shipping rate calculated at checkout.
      • Purchase Order & instructions box available at Cart page

        • Pay securely! All major cards accepted.

          shop pay
        ACMA licensing for HF, VHF and UHF radio: class licence, CB or an assigned land mobile licence — and how each shapes your antenna design Design guide ACMA licensing for HF, VHF and UHF radio: class licence, CB or an assigned land mobile licence — and how each shapes your antenna designBefore you buy a two-way radio system, know which of the three ACMA paths it will run under: a class licence you never apply...Read the guide

        Product Description

        RFI UHF Antenna (HPA-4245-SMAF) SMA(F) is designed for robustness and reliability. This HPA antenna offers superior performance in a variety of frequency bands. It is factory tuned and ideal for workshop use, ensuring ease of installation and optimal performance.

        Features:

        • Connector Options for UHF Antenna: Available with SMA (female), MX, and BNC (male) connectors to suit most radios.
        • Factory Tuned: Antennas are supplied factory tuned for ease of installation.
        • Robust Construction: Engineered to withstand extreme conditions of temperature and humidity.
        • Attractive Styling: Features an attractive and modern design.
        • Superior Performance: Offers superior performance for reliable communication.
        • Workshop Use for UHF Antenna: Most models are ideal for workshop use.

        Specifications of RFI UHF Antenna:

        • Frequency MHz: 420-450MHz
        • Gain: Unity
        • Impedance Ohm: 50
        • VSWR: ≤2.0:1
        • Bandwidth MHz: 5%
        • Dimensions mm (approx.): 165
        • Polarization: Vertical
        • Radome: TPE
        • IP Rating: IP67
        • Operating Temp. °C: -20 to +65

        Documents:

        RFI HPA-4245-SMAF Hand Portable Antenna - Datasheet

        Product Specifications

        Brand RFI
        Length (cm) 20
        Width (cm) 3
        Height (cm) 3
        Antenna Application Handheld Antenna
        Antenna Configuration SISO
        Antenna Port Connectors SMA (F)
        Antenna Type Ground Independent
        Connector VHF SMA female
        Coverage Type Omni-directional
        Frequency [MHz] 260-800
        Frequency Band UHF 380-520 MHz
        Ingress Protection (IP) IP67
        Installation Type Device mounting
        Low PIM No
        Max Frequency (MHz) 450
        Max Gain (dBd/dBi) 1
        MIMO Support No
        Min Frequency (MHz) 420
        Min Gain (dBd/dBi) 1
        Mount Supported Connector mount
        Mount Supported - Detailed Device mount
        No. of Antenna Ports 1
        Technologies Supported UHF
        VSWR <2.0:1
        Whip Length mm 165mm
