The Maxon MA-6060 4G Modem with Ethernet delivers fast and reliable LTE CAT6 connectivity with dual SIM support and Band 28 compatibility. With 300 Mbps downlink and 50 Mbps uplink speeds, it ensures seamless network performance. This industrial-grade router features dual-band Wi-Fi (802.11 ac/b/g/n), 4 Ethernet LAN ports, and a configurable WAN/LAN port for flexible networking.
Product Features:
- The device supports LTE CAT6 with Band 28 compatibility.
- It features 6-band DC-HSPA+ for enhanced connectivity.
- Dual SIM functionality ensures network redundancy.
- The built-in dual-band Wi-Fi supports IEEE 802.11ac and is compatible with IEEE 802.11b/g/n standards.
- It includes four Ethernet LAN ports for wired connections.
- One Ethernet WAN port is available, which can also be configured as an additional LAN port.
- RS-232 connectivity is provided via a 3-wire console port adapter.
- The digital I/O interface includes two inputs, one output, and one relay for industrial applications.
- The device supports a maximum downlink speed of 300 Mbps and an uplink speed of 50 Mbps.
- FOTA (Firmware Over-The-Air) updates are supported for easy maintenance.
- DDNS (Dynamic DNS) support enables remote access flexibility.
- Remote management is possible via SMS control.
- Multiple communication protocols are supported, including SSH, TCP Server, TCP Client, UDP Server, and UDP Client.
- A low power consumption mode is available, featuring sleep mode and scheduled online/offline modes.
- The device supports simultaneous Access Point and Client modes.
- Accessories include a 12V DC power supply for reliable operation.
Application Areas:
- Industrial and Remote Site Connectivity
- Smart Cities and IoT Networks
- Transportation and Vehicle Networks
- Retail and Business Failover Internet
- Security and Surveillance Systems
- Traffic and Signals
- Media Transfer and Video Surveillance
- Security with Real-Time monitoring
- Broadcast
Kit Includes:
- 1 x MA-6060 Modem
- 2 x Cellular Mag Mount Antennas
- 2 x Wi-Fi Elbow Antenna
- 1 x GPO Plug Pack
- 1 x Ethernet Cable
- 1 x Serial Cable
- 1 x Terminal Block
Documents:
Maxon MA-6060 Quadmax Router - Brochure
Maxon MA-6060 4G Modem with Ethernet - Datasheet
