The Poynting MIMO-3-14 Antenna exceeds the performance of most competitors due to the attention to the design of this high-performance antenna. The radiation patterns of all radiating elements provide an excellent balance between omnidirectionality, pattern diversity and good radiation abilities at the desired elevation. This is an important criterion for the transportation and marine market. which the antenna was specifically designed for.

Product Features:

• The antenna operates over an ultra-wideband frequency range covering 410–470 MHz, 617–2700 MHz, and 3400–3800 MHz bands.
• The cleverly designed decorrelated antenna elements deliver superior MIMO performance across the cellular bands.
• It includes a high-performance GPS/GLONASS module for accurate positioning and navigation.
• Its robust mechanical design provides ruggedness as well as protection against corrosion, water, and dust (IP69K rated).
• The MIMO-3 model features an internal ground plane, making it suitable for installation on any surface type.

Application Areas:

• It supports transport broadband, automation, and telemetry applications for buses, utility vehicles, trucks, and public safety fleets.
• It is ideal for industrial factory automation, robotic machinery, and other machine-to-machine telemetry systems.
• It facilitates farming and agricultural automation deployments, including M2M and IoT use cases.
• It enables broadband cellular distribution for marine vessels, including inland boats and near-coastal crafts.
• It supports communications, telemetry, and automation systems for mining vehicles and heavy machinery (M2M & IoT).

In the Box:

• 1x Poynting MIMO-3-14 Transportation Antenna - White

Documents:

Poynting MIMO-3-14 Antenna - Datasheet

Videos:

MIMO-3 Antenna Installation on a Caravan/RV/Campervan
