Pulse PSP6927-2310-N 3-port Directional Coupler, 698-2700 MHz, 10 dB, N-Female

    Pulse PSP6927-2310-N 3-port Directional Coupler, 698-2700 MHz, 10 dB, N-Female

      Product form
      Brand:
      Pulse
      Item ID:
      168030294
      Export:
      Accepted
      Shipping:
      Not available to ship
      Warranty:
      Standard Warranty
      Product Liability:
      Global Insurance Except USA & Canada
      MPN/Options:
      PSP6927-2310-N
      Request for Quote (RFQ) Discount Offers Shipping Policy Returns Policy
      Pulse 3-port Directional Couplers offer a low-cost solution, covering cellular bands from 698 to 2700 MHz, with low loss and low Passive Inter-Modulation performance.

      Sold-out

      $66.55

      • Taxes included. Shipping rate calculated at checkout.
      • Purchase Order & instructions box available at Cart page

        • Pay securely! All major cards accepted.

          shop pay

        Product Description

        Pulse 3-port Directional Couplers offer a low-cost solution, covering cellular bands from 698 to 2700 MHz, with low loss and low Passive Inter-Modulation performance. Typically used for a variety of RF combining including distributing power through RF networks, including into antenna feeders or in-building Distributed Antenna Systems, top optimize and balance system levels.

        Product Features:

        • Broadband 698-2700 MHz covering multi-cellular bands.
        • Manufactured to a low PIM -150 dBc (3rd Order 2x43 dBm carriers) rating.
        • Suitable for use in multi-carrier environments.
        • Available in either 6 dB or 10 dB coupling values.

        Application Areas:

        • Distributed Antenna Systems (DAS).
        • Cellular network infrastructure.
        • Signal optimization in multi-carrier environments.
        • Feeder cable network integration.

        In the Box:

        • Pulse PSP6927-2310-N 3-port Directional Coupler, 698-2700 MHz, 10 dB, N-Female

        Documents:

        PSP6927-23xx-N Directional Coupler - Datasheet

        Product Specifications

        MPN PSP6927-2310-N
        Brands Pulse
        Connector N(F)
        Finish Painted Black
        Frequency range mhz 698 - 2700
        Height 3.5
        Impedance 50 Ohm
        Insertion loss db <0.7
        Length 24
        Pim 3rd 2 43 dbm dbc < - 150 dBc
        Ports 3
        Power w 200
        Return loss vswr 19dB / 1.25:1
        Technology type 4G, UMTS
        Temperature range c -25 to +65
        Width 8
