RFI SP6938-2330-4.3 Directional Coupler 3 Port, 30 dB, 694-3800 MHz, 200W, 4.3-10-Female

    RFI SP6938-2330-4.3 Directional Coupler 3 Port, 30 dB, 694-3800 MHz, 200W, 4.3-10-Female

      Product form
      Brand:
      RFI
      Item ID:
      168021609
      Export:
      Accepted
      Shipping:
      Ships out in 1-2 business days
      Warranty:
      Standard Warranty
      Product Liability:
      Global Insurance Except USA & Canada
      MPN/Options:
      SP6938-2330-4.3
      Request for Quote (RFQ) Discount Offers Shipping Policy Returns Policy
      RFI Directional Coupler 3 Port 30 dB 694-3800 MHz 200W; 4.3-10(F)used in a variety of RF combining, sampling RF for fibre fed systems anddistributing power

      Available

      $126.00

      • Taxes included. Shipping rate calculated at checkout.
      • Purchase Order & instructions box available at Cart page

        • Pay securely! All major cards accepted.

          shop pay

        Product Description

        RFI Directional Coupler 3 Port 30 dB 694-3800 MHz 200W; 4.3-10(F)

        RFI 3-Port Directional Couplers are used in a variety of RF combining, sampling RF for fibre fed systems and or distributing power throughout feeder cable networks. RFI provide a wide product range of coupling values in the most popular frequency bands which enables optimised and balanced system levels.

        Features:

        • Broadband 694-3800MHz covering multi-cellular bands
        • Manufactured to a low PIM ? -160dBc (3rd Order 2x43dBm carriers) rating
        • Primarily used for optimising feeder cable signal distribution.
        • Suitable for use with simplex and duplex channels, analogue or digital communications.
        • Suitable for use in multi-carrier environments
        • Wide range of coupling values up to 30dB
        • Environmental IP 65 Rating.
        Models available SP6938-23xx-4.3, where xx: | 05 | 06 | 07 | 08 | 10 | 13 | 15 | 20 | 30 |

        Product Specifications

        MPN SP6938-2330-4.3
        Brands RFI
        Component type Directional Coupler
        Conn types all term ports 4.3-10 (F)
        Connector 4.3-10 (F)
        Coupled loss db 30
        Finish Black - Painted
        Frequency band Cellular
        Height 8
        Length 26
        Pim 3rd 2 43 dbm dbc <160dBc
        Width 15
