RFI SP6938-2306-4.3 Directional Coupler, 3 Port, 6 dB, 694-3800 MHz, 200W, 4.3-10-Female

Name: RFI SP6938-2306-4.3 Directional Coupler, 3 Port, 6 dB, 694-3800 MHz, 200W, 4.3-10-Female
Brand: RFI
SKU: 168021581
Price: 126.0 AUD
Availability: InStock

Product form

Brand:

RFI

Item ID:

168021581

Export:

Accepted

Shipping:

Ships out in 1-2 business days

Warranty:

Standard Warranty

Product Liability:

Global Insurance Except USA & Canada

MPN/Options:

SP6938-2306-4.3

Request for Quote (RFQ) Discount Offers Shipping Policy Returns Policy

RFI Directional Coupler 3 Port 6 dB 694-3800 MHz 200W; 4.3-10(F) are used in a variety of RF combining, sampling and power splitting applications.

Available

$126.00

Taxes included. Shipping rate calculated at checkout.

Purchase Order & instructions box available at Cart page

Pay securely! All major cards accepted.

Product Description

RFI Directional Coupler 3 Port 6 dB 694-3800 MHz 200W; 4.3-10(F)

RFI 3-Port Directional Couplers are used in a variety of RF combining, sampling RF for fibre fed systems and or distributing power throughout feeder cable networks. RFI provide a wide product range of coupling values in the most popular frequency bands which enables optimised and balanced system levels.

Features:

Broadband 694-3800 MHz covering multi-cellular bands
Manufactured to a low PIM ? -160 dBc (3rd Order 2x43 dBm carriers) rating
Primarily used for optimising feeder cable signal distribution.
Suitable for use with simplex and duplex channels, analogue or digital communications.
Suitable for use in multi-carrier environments
Wide range of coupling values up to 30 dB
Environmental IP 65 Rating.

Models available SP6938-23xx-4.3, where xx: | 05 | 06 | 07 | 08 | 10 | 13 | 15 | 20 | 30 |

Product Specifications

MPN	SP6938-2306-4.3
Brands	RFI
Component type	Directional Coupler
Conn types all term ports	4.3-10 (F)
Connector	4.3-10 (F)
Coupled loss db	6
Finish	Black - Painted
Frequency band	Cellular
Height	8
Length	26
Pim 3rd 2 43 dbm dbc	<160dBc
Width	15
