RFI COD8-99 UHF Enclosed Dipole Antenna, 600-960 MHz, 2 dBi, N-Female

Name: RFI COD8-99 UHF Enclosed Dipole Antenna, 600-960 MHz, 2 dBi, N-Female
Brand: RFI
SKU: 167015355
Price: 543.67 AUD

Product form

Brand:

Item ID:

167015355

MPN:

COD8-99

Export:

Restricted

Shipping:

Please contact us for lead time

Warranty:

Standard Warranty

Product Liability:

Global Insurance Except USA & Canada

UHF Enclosed Dipole 600-960 MHz Custom Tuned are a range of fibreglass enclosed vertical dipoles, ideal in point to multipoint, trunking, cellular

$543.67

Product Description

Available spot tuned to user specified frequencies or in a number of pre-determined band configurations.
Excellent null fill coverage.
Omnidirectional unity gain performance.

Brand	RFI
Length	80
Width	3
Height	3
Antenna Application	Base Station Antenna
Antenna Features	Omnidirectional
Antenna Port Connectors	N (F)
Antenna Type	Vertical Dipoles
Construction	Alodined aluminium elements with white fibreglass radome
Coverage Type	Omni-directional
Frequency [MHz]	600-960
Frequency Band	900 MHz, 700 MHz, 800 MHz
Horizontal Beamwidth	Omni +/- 0.5dB
Installation Type	External mounting
Low PIM	No
Max Frequency (MHz)	960
Max Gain (dBd/dBi)	2
MIMO Support	No
Min Frequency (MHz)	600
Min Gain (dBd/dBi)	2
Mount Supported	Clamp mount
Mount Supported - Detailed	UB1
Mounting Area	230mm (minimum) x 25mm diam. alodined aluminium
No. of Antenna Ports	1
Nominal Gain [dBi]	2
Power [W]	100
Technologies Supported	UHF
Termination	N female bulkhead
Torque [Nm]	8
Tuned Bandwidth	80 MHz
Vertical Beamwidth	78?
Wind Gust (km/h)	>240
Wind Thrust	34
