The Victron MultiPlus-II 12/3000/120-32 is a high-performance inverter/charger that delivers powerful energy management for mobile and off-grid applications. Designed for 12V systems, it combines a 3000VA (2400W) pure sine wave inverter with an intelligent 120A battery charger and a 32A automatic transfer switch, all in one compact unit. Ideal for energy storage systems, marine, RV, and residential backup setups, it ensures seamless power conversion and battery management.
Product Features:
- The Victron MultiPlus-II 12V, 3 kVA Inverter Charger features a high-performance inverter capable of delivering 3000VA (2400W) of continuous power with a pure sine wave output.
- It includes a powerful 120A adaptive battery charger that intelligently adjusts its multi-stage charging process based on the battery type and condition, and is fully compatible with Lithium, AGM, Gel, and other common battery technologies.
- An integrated 32A automatic transfer switch allows seamless switching between grid or generator input and inverter power.
- The unit is equipped with Victron's advanced PowerAssist technology, which prevents AC overloads by supplementing grid or generator power with energy from the battery.
- The system supports both parallel operation and three-phase configurations, making it scalable for higher power demands in complex installations.
- For enhanced control and monitoring, the inverter charger is compatible with Victron’s Remote Management (VRM) portal and can be integrated with GX devices to allow remote access and configuration.
- Housed in a compact and robust enclosure, the MultiPlus-II is designed for durability and ease of installation in a variety of environments, including mobile, marine, and residential energy systems.
Application Areas:
- Off-grid Solar Power Systems
- Recreational Vehicles (RVs) & Motorhomes
- Marine & Boat Power Solutions
- Residential Backup Power
- Mobile Workstations and Remote Installations
- Battery-Based Energy Storage Systems (ESS)
In the Box:
- 1 × Victron MultiPlus-II 12 3000 (2400W) Inverter Charger -PMP122305010
Documents:
Victron MultiPlus-II GX - Manual
Victron MultiPlus-II GX - Datasheet
