X10DR XRTG Pairing Button

Operating in the 2.4 GHz band means antenna coax cable losses can be significant. Even the best available coax suffers a 3 dB loss on a 5.5 meter (17 ft) cable run. That's the equivalent of losing half the RF signal! Of most importance, that means greater into building penetration than with a standard internally mounted gateway device. The XRTG Plus ruggedized housing mounts on a stainless L shape bracket and is fully weatherproof against the elements. XRTG operation has been confirmed up to 92C (197F) and down to -30C (-22F) meaning it can operate externally in most environment extremes including external use on Fire engines. TOUCHLESS PAIRING PROCESS of X10DR XRTG Pairing Button Simply insert XRPB pairing button and triple press. Next hold the handset nearby, pressing both its blue buttons until the blue LED flashes rapidly and the handset beeps (after 5 secs). A few seconds later pairing confirmation tones will sound and the LED on the handset will glow solid.
